Multi-Factor Authentication API

Individual API

The MFA API provides multi-factor authentication setup and management.

Quick Navigation

Overview​

This module supports:

  • TOTP (Time-based One-Time Password) via authenticator apps
  • Email OTP
  • Backup codes
  • Device management

Base Path​

All MFA endpoints are prefixed with /api/v1/mfa

Authentication​

All endpoints require authentication:

Authorization: Bearer <access_token>

MFA Flow​

The MFA system provides multiple authentication methods to enhance account security. Users can set up TOTP, Email OTP, or use backup codes as recovery options. The system supports device trust to streamline the authentication experience for trusted devices.

MFA Flow Diagram​

View Flow Diagram

MFA Flow Diagram

MFA Flow Overview:

This flow diagram illustrates the complete MFA authentication decision tree. It shows how the system evaluates MFA requirements, device trust status, and handles different MFA methods.

Key Flow Components:

  1. MFA Check: System verifies if MFA is enabled for the user account
  2. Device Trust Evaluation: For MFA-enabled accounts, checks if the device is trusted
  3. MFA Method Selection: User can choose between TOTP, Email OTP, or Backup Codes
  4. Code Verification: Validates the provided MFA code with rate limiting
  5. Device Trust Option: User can choose to remember the device for future logins
  6. Account Protection: Failed attempts trigger account lockout after 3 tries

Internal Developer Notes:

  • Device trust bypasses MFA challenge for trusted devices
  • Each MFA method has its own verification process and expiration times
  • Rate limiting prevents brute-force attacks on MFA codes
  • Backup codes are single-use and expire after use
  • Device trust tokens expire after 5 minutes if not activated

MFA Setup Flow (TOTP)​

View MFA Setup Flow Diagram

MFA Verification Flow (During Login)​

View MFA Verification Flow Diagram

Backup Codes Flow​

View Backup Codes Flow Diagram

Validations​

TOTP Setup Validations​

  • Device name uniqueness check (optional)
  • TOTP secret generation (RFC 6238 compliant)
  • QR code generation with proper encoding
  • Backup code generation (10 codes, 8 characters each)
  • Rate limiting: 3 setup attempts per 60 seconds

TOTP Verification Validations​

  • Code format validation (6 digits)
  • Time window validation (30 seconds tolerance)
  • Rate limiting: 3 attempts per 60 seconds
  • Lockout after 3 failed attempts (60 seconds)

Email OTP Setup Validations​

  • Primary email verification check
  • Email OTP uniqueness check
  • Backup code generation

Email OTP Verification Validations​

  • OTP code format (6 digits)
  • OTP expiration check (10 minutes)
  • Rate limiting: 3 attempts per 60 seconds
  • Attempt limit: 5 max attempts per OTP

Backup Codes Validations​

  • Code format validation (8 alphanumeric characters)
  • One-time use validation
  • Code expiration check
  • Hash verification

Security Features​

  • TOTP secret stored securely (not retrievable after setup)
  • Backup codes hashed with bcrypt
  • One-time use for backup codes
  • Rate limiting on verification attempts
  • Account lockout after failed attempts
  • Audit logging for all MFA operations
  • Automatic backup code generation on setup
  • Primary method designation

Endpoints​

MethodEndpointDescription
POST/totp/setupSetup TOTP MFA
POST/totp/verifyVerify TOTP setup
POST/email-otp/setupSetup Email OTP MFA
POST/email-otp/verifyVerify Email OTP setup
GET/statusGet MFA status
GET/totp/devicesList TOTP devices
DELETE/totp/devices/{device_id}Remove TOTP device
POST/backup-codes/generateGenerate backup codes
GET/backup-codesGet masked backup codes
POST/totp/resetReset TOTP setup

Internal Notes​

  • All endpoints are fully implemented
  • Rate limiting on verification endpoints (3 attempts, 60s lockout)
  • Backup codes are automatically generated on MFA setup
  • TOTP supports multiple devices per user
  • Email OTP uses the OTP service for code generation
  • MFA status integrates with device trust for login flows

Swagger Documentation​

Interactive API documentation available at: /docs#/mfa
